SIMULINK ialah suatu perangkat lunak
yang dapat digunakan untuk membuat simulasi dalam bentuk/model sistem
matematika. Didalam simulink ini terdapat blok pustaka yang isinya meliputi
antara lain :
1
Sources mempunyai pustaka antara lain : clock, digital clock, signal generator, constant, sine wave, step input, pulse generator
random number, from file, from
workkspace, signal, band limited white noise, repeating squence
2
Sinks mempunyai pustaka antara lain : scope, graph, stop simulation, XY graph, hit crossing, to workspace,
to file, auto-scale garph
3
Discrete mempunyai pustaka antara lain : unit delay, filter, discrete state-space, zero-order hold, first order
hold, discrete time integrator, discrete time limeted integrator, transfer
function, discrete zero-pole.
4
Linear mempunyai pustaka anatara lain : sum, integrator, gain, matrix gain, slider gain, transfer function,
zero-pole, state space, inner product, derivative.
5
Nonlinear mempunyai pustaka anatara lain : sign, relay, backlash, saturation, quantizer, memory, transport delay,
variable transport delay, matlab function, function, s-function, reset integrator,
switch, combinatorial logic, logical operator, relational operator, product,
abs, look up table, 2-D look up table, dead zone, dan rate limiter
6
Connections mempunyai pustaka antara lain : inport, outport, mux, demux.
7
Extras mempunyai pustaka antara lain : simulink demos, most commonly used blocks, conversion, flip-flops, PID
Controllers, analyzers, controllers, filters, system ID, robust control demo,
mu tools demos, neural networks.
Sumber
Buku Panduan Praktikum Mr. SK
